Alinco DM-430E 30A Power supply

Disponible para reserva
Código de producto: AIC1002352 EAN: 4969182310191
Precio regular €199,00 EUR IVA incluido
¡Descubra los tiempos y costos de envío al finalizar la compra!
Fuente de alimentación conmutada ultracompacta 9-15V - 30A máx.

These supplies have 5-15VDC variable output and deliver up to 30A peak power. They are designed for the electronics hobbyist and 2-Way radio communication use. They are ideal for Amateur Radio transceivers that require a 13.8V DC external supply.

Features include a large, illuminated, digital Volt/Amp meter, rear panel binding posts (30A peak), added front panel Anderson PowerPole® terminals (30A/peak) providing versatility and quick connection.

Voltage adjustment is 5-15 volts, or switch to fixed-voltage at 13.8V. Power supply ripple is less than 80mVp-p and protection is provided for short-circuit, over temperature, and current limiting!

Specification :

  • Power Supply Type: switch mode
  • Peak Output: 30A at 13.8 Vdc
  • Voltage Adjustment Control: Front panel
  • Voltage Adjustment Range: 5.0-15.0 Vdc
  • Metering Type: Dual meters
  • High Current Terminal Location: Front/Rear panel
  • Cooling Type: Fan
  • Width: 4.921 in. Height: 2.362 in. Depth: 6.299 in.
  • Weight: 3.53 lbs.
  • Nominal 230 V AC input.
